DJI Zenmuse X5S

Vendor Part Number

As low as $2,049.00

  • Compatible with Inspire 2 & Matrice 200 Series
  • 4/3-Inch 20.8MP CMOS Sensor
  • Dynamic Range of 12.8 Stops
  • Supports Multiple Micro 4/3 Lenses
  • Video Resolution up to 5.2K (CinemaDNG)
  • DNG, JPEG, and DNG+JPEG Image Formats
  • RAW, ProRes, MOV, and MP4 Video Formats

In stock


Give Us A Call

Kevin Hale - Drone Expert

(213) 262-9436
Customize DJI Zenmuse X5S
1 x DJI Zenmuse X5S   + $2,049.00

* Required Fields

    DJI Zenmuse X5S
    DJI Zenmuse X5S

    In stock


    High-End Professional Aerial Imagery

    One of DJI’s most powerful aerial cameras, the Zenmuse X5S is precisely engineered to deliver superb results for a wide variety of aerial photography and videography applications. Equipped with an upgraded 20.8-megapixel Micro 4/3 CMOS sensor, this camera offers a high dynamic range of 12.8 stops, which allows it to effectively handle high-contrast scenes and capture images and videos that retain a wealth of detail in all areas of the image. Along with a significantly improved the signal-to-noise ratio and enhanced color sensitivity, the X5S is able to produce sharp, low-noise imagery in various lighting situations.

    In addition to its impressive photography capabilities, the Zenmuse X5S is a highly effective aerial imaging tool for professional filmmakers due to its superior video resolution. With the integrated CineCore 2.0 image processing system on the Inspire 2, it can record movie-quality videos in 5.2K CinemaDNG and Apple ProRes, as well as 4K video in H.264 and H.265 (both at a bitrate of up to 100Mbps).

    Interchangeable Lens Capability

    Having a fixed lens can be limiting for users who want more creative flexibility when it comes to their final output. The Zenmuse X5S can be used with a variety of compatible interchangeable micro 4/3 lenses, allowing you to choose the most appropriate lens type or focal length to fit your shooting needs. It currently supports eight standard micro 4/3 prime and zoom lenses from Olympus, Panasonic Lumix, and DJI, with focal lengths ranging from 9 to 45mm.

    Optimized Gimbal Stabilization

    DJI Zenmuse X5S offers ultra-smooth gimbal stabilization thanks to an improved 3-axis mechanical gimbal that makes use of concealed wires, vibration damping balls, a lightweight damping board, and a dedicated processor to ensure full 360° rotational capability, a control accuracy of ±0.01°, enhanced durability, optimum stability, and stable, uninterrupted data transmission. The gimbal allows the user to capture crisp, highly detailed photos and cinematic, shake-free video footage even when using heavier lenses with longer focal lengths or when flying in less than ideal weather conditions.

    High-Speed Workflows

    The Zenmuse X5S utilizes DJI CINESSD card (PCIe3.0 NVMe SSD support) along with an advanced FAT32/exFAT file format system to record and transfer data at write speeds of up to 4.2Gbps. This allows for faster direct video transfer to a computer through the DJI CINESSD Station card reader, thus supporting more efficient CinemaDNG and Apple ProRes editing workflows.

    Continuous Burst Mode and Lossless In-Video Still Capture

    Even when capturing multiple photos at high speeds, the Zenmuse X5S is capable of storing and maintaining as much detail, sharpness, and image information as possible. This allows the X5S to shoot 14 frames per second in JPEG+DNG format with a maximum resolution of 20.8 megapixel. But when the CINESSD program is used, the burst photo frame rate can be increased to up to 20fps.

    The Zenmuse X5S can also create lossless still image files captured from a video without interrupting the recording.

    Exceptional Long-Range Control

    Adjust camera settings such as aperture and focus using the dedicated DJI GO 4 app, which allows users to operate the Zenmuse X5S remotely to ensure maximum image quality and total creative control. Combined with DJI’s new Lightbridge technology, commands can be transmitted in real-time from up to 4.3mi (7km) away. When used with DJI Focus, an optional follow focus mechanism, users can enjoy ultra-precise control over lens focusing to ensure that subjects and scenes are always kept in sharp focus.


    NameZenmuse X5S
    Dimensions140×98×132 mm
    Weight461 g


    Supported LensDJI MFT 15mm/1.7 ASPH (With Balancing Ring and Lens Hood)
    Panasonic Lumix 15mm/1.7 (With Balancing Ring and Lens Hood)
    Panasonic Lumix 14-42mm/3.5-5.6 HD
    Olympus M.Zuiko 12mm/2.0 (With Balancing Ring)
    Olympus M.Zuiko 17mm/1.8 (With Balancing Ring)
    Olympus M.Zuiko 25mm/1.8
    Olympus M.Zuiko 45mm/1.8
    Olympus M.Zuiko 9-18mm/4.0-5.6
    SensorCMOS, 4/3”
    Effective Pixels: 20.8MP
    FOV72° (with DJI MFT 15mm/1.7 ASPH )
    Photo Resolutions4:3, 5280×3956
    16:9, 5280×2970
    Video ResolutionsAspect Ratio 17:9

    4K DCI: 4096×2160 23.976/24/25/29.97p,
    up to 2.4Gbps; 50/59.94p, up to 4.0Gbps

    4K DCI: 4096×2160 23.976/24/25/29.97/47.95/50/59.94p @100Mbps

    4K DCI: 4096×2160 23.976/24/25/29.97p @100Mbps

    Aspect Ratio 16:9

    4K Ultra HD: 3840×2160 23.976/24/25/29.97p,
    up to 2.4Gbps; 50/59.94p, up to 4.0Gbps

    4K Ultra HD: 3840×2160 23.976/24/25/29.97p,
    422 HQ @900Mbps; 23.976/24/25/29.97p, 4444 XQ @2.0Gbps

    4K Ultra HD: 3840×2160 23.976/24/25/29.97/47.95/50/59.94p @100Mbps
    2.7K: 2720×1530 23.976/24/25/29.97p @80Mbps; 47.95/50/59.94p @100Mbps
    FHD: 1920×1080 23.976/24/25/29.97p @60Mbps;
    47.95/50/59.94p @80Mbps; 119.88p @100Mbps

    4K Ultra HD: 3840×2160 23.976/24/25/29.97p @100Mbps
    2.7K: 2720×1530 23.976/24/25/29.97p @65Mbps;
    47.95/50/59.94p @80Mbps
    FHD: 1920×1080 23.976/24/25/29.97p @50Mbps;
    47.95/50/59.94p @65Mbps; 119.88p @100Mbps

    Aspect Ratio 2.44:1

    5.2K: 5280×2972 23.976/24/25/29.97p, up to 4.2Gbps

    5.2K: 5280×2160 23.976/24/25/29.97p, 422 HQ @1.3Gbps

    4K Ultra HD: 3840×1572 23.976/24/25/29.97p @100Mbps
    Photo FormatsDNG,JPEG,DNG+JEPG
    Video FormatsRAW,ProRes,MOV,MP4
    Operation ModesCapture, Record, Playback
    Still Photography ModesMicro SD: Single shot, Burst Shooting:
    3/5/7/10/14 frames, Auto Exposure Bracketing, 3/5 bracketed frames at 0.7EV bias, Timelapse
    SSD: RAW Burst Shooting:
    3/5/7/10/14/20/∞ frames
    Exposure ModeAuto, Manual, Shutter, Aperture
    Exposure Compensation±3.0 (1/3 increments)
    Metering ModeCenter-weighted metering,
    Spot metering (area option 12x8)
    AE LockSupported
    Electronic Shutter Speed8-1/8000s
    White Balance Auto, Sunny, Cloudy, Incandescent,
    Neon Custom (2000K–10000K)
    ISO Range100 – 6400 (Video)
    100 – 25600 (Stills)
    Video CaptionsSupported
    Anti-FlickerAuto, 50Hz, 60Hz


    Angular Vibration Range±0.01°
    Controllable RangeTilt: +30°to -90°, Pan: ±320°
    Mechanical RangeTilt: +50°to -140°, Pan: ±330°, Roll: +90° to +30°
    Max Controllable SpeedTilt: 90°/s, Pan: 90°/s


    Operating Temperature14°–104°F (-10 to 40℃)
    Storage Temperature-4°–140°F (-20 to 60℃)
