DJI Matrice 300 RTK - H20 Lens Kit

As low as $12,388.00

The new standard in drones for enterprise applications
Includes Zenmuse H20
Includes DJI Care Enterprise protection plans
9.3 miles max transmission range
6 directional sensing and positioning
IP44 water + dust protection in -4°F to 122°F Operating temperatures
23x Hybrid Optical Zoom
12mp wide and 20 mp zoom cameras
"Night Scene" IR-Cut mode
All-New Smart Inspection features
Does not include batteries or charger (add in "Configure Your Bundle" section)
Limited Time: Includes 1 Day of Free In-Person Training at Your Location

In stock

Give Us A Call

Kevin Hale - Drone Expert

(213) 262-9436

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Customize DJI Matrice 300 RTK - H20 Lens Kit

Matrice 300 RTK - H20 Lens Kit

1 x DJI Matrice 300 RTK - H20 Lens Kit +

Add Batteries (2 Required for each flight)

Quantity

Add Battery Station (Charger)

Quantity

Add GPC Case

Quantity

Add 1 day of free training

Quantity

* Required Fields

Summary

Total

DJI Matrice 300 RTK - H20 Lens Kit

In stock

$12,388.00

Details

DJI Matrice 300 RTK: Built Tough. Works Smart.

A new standard for the commercial drone industry

The Matrice 300 RTK takes inspiration from modern aviation systems. Offering up to 55 minutes of flight time, advanced AI capabilities, 6 Directional Sensing & Positioning, and more, the M300 RTK sets a whole new standard by combining intelligence with high-performance and unrivaled reliability.

Features:

9.3 miles max transmission range
55 minute max flight time
6 directional Sensing and Positioning
Redesigned primary flight display
IP45 water and dust protection
-4°F to 122°F Operating temperature
Hot-swappable battery
UAV Health Management System

Improved transmission system

The all-new OcuSync Enterprise enables transmission up to 15 km away and supports triple-channel3 1080p video. Real-time auto-switching between 2.4 GHz and 5.8 GHz4 enables more reliable flight near high-interference environments, while AES-256 encryption offers secure data transmission.

Enhanced flight performance

The refined airframe and propulsion system design gives you a more efficient and stable flight, even in harsh conditions

Multiple payload configurations

Configure your M300 RTK to fit your mission needs. Mount up to 3 payloads simultaneously, with a maximum payload capacity of 2.7 kg.

Smart Inspection

Live Mission Recording
Record mission actions such as aircraft movement, gimbal orientation, photo shooting, and zoom level to create sample mission files for future automated inspections.

AI Spot-Check
Automate routine inspections and capture consistent results every time. Onboard AI recognizes the subject of interest and identifies it in subsequent automated missions to ensure consistent framing. (Only compatible with H20/H20T)

Waypoints 2.0
Create up to 65,535 waypoints and set multiple actions for one or more payloads, including 3rd party ones, at each waypoint. Flightpath planning is also optimized to maximize flexibility and efficiency for your missions.

PinPoint
A quick tap marks an object in view, advanced sensor fusion algorithms immediately deliver its coordinates.

Smart Track
Identify and follow moving subjects like people, vehicles, and boats with the auto-zoom function, while continuously acquiring the subject's dynamic location.

Location Sharing
While either PinPoint or Smart Track is enabled, the subject's location can be projected across multiple camera views, to another remote controller, or shared through online platforms such as DJI FlightHub.

Aviation-grade situational awareness

The M300 RTK adopts a new Primary Flight Display (PFD) that integrates flight, navigation, and obstacle information to empower the pilot with exceptional situational awareness

Flight Information
Flight information such as aircraft attitude, altitude, and velocity, as well as wind speed and wind direction, are all intuitively presented.

Navigation display
Pilots can also view the live status of the aircraft's heading, trajectory, PinPoint information, and home point projection, in a more efficient way. Visualize all nearby obstacles at once with the new obstacle map, so you can be fully informed.

Advanced dual control
Either operator can now obtain control of the aircraft or payload with a single tap. This creates new possibilities for mission strategies as well as higher flexibility during operations.

A powerful vision system you can rely on
To enhance in-flight safety and aircraft stability, dual-vision and TOF sensors appear on all six sides of the aircraft, offering a maximum detection range of up to 40m, with options to customize the aircraft's sensing behavior via the DJI Pilot App. Even in complex operating environments, this 6 Directional Sensing and Positioning system helps keep the aircraft and the mission safe.

Professional Maintenance for your drone
The new integrated Health Management System displays the current status of all systems, notification logs, and a preliminary troubleshooting guide. Also in the system are the aircraft's flight logs, duration, and mileage throughout its entire lifecycle, and tips on aircraft care and maintenance.

Redundancy systems for safer flights
The M300 RTK's built-in advanced redundancy systems help keep your critical missions going even in unexpected scenarios.

1 Day In-Person Training at Your Location Included

For a limited time only, included with the purchase of each Matrice 300 RTK is DSLRPros' 1 Day In-Person Training Session. This in-depth and hands-on instructional program will familiarize you with the Matrice 300 RTK, and teach you how to get the most out of your craft while flying safely and confidently. One of our knowledgeable and experienced flight instructors will travel to your location at a time that is convenient for you or your team and demonstrate how to get started flying and using the most exciting features that the Matrice 300 RTK has to offer.

For those who are interested in learning even more about using the M300 as well as specific use case training, DSLRPros offers an optional second day of custom-tailored training at a reduced price when booked with the complimentary one-day training. Learning how to operate your Matrice 300 RTK safely and effectively is the best way to maximize your investment, and get the most out of this amazing tool.
Contact us for more information.

Specifications

Matrice 300

Aircraft

Dimensions: Unfolded, propellers excluded, 31.9×26.4×16.9 in (L×W×H) | Folded, propellers included, 16.9×16.5×16.9 in (L×W×H)
Diagonal Wheelbase: 35.2 in
Weight (with single downward gimbal): Approx. 7.9 lb (without batteries) | Approx. 13.9 lb (with two TB60 batteries)
Max Payload: 6 lb
Max Takeoff Weight: 19.8 lb
Operating Frequency: 2.4000-2.4835 GHz | 5.725-5.850 GHz
EIRP: 2.4000-2.4835 GHz: 29.5 dBm (FCC) | 5.725-5.850 GHz: 28.5 dBm (FCC)
Hovering Accuracy (P-Mode w/ GPS) - Vertical: ±4 in（Vision System enabled）| ±19.7 in（GPS enabled）| ±4 in（RTK enabled）
Hovering Accuracy (P-Mode w/ GPS) - Horizontal: ±11.8 in（Vision System enabled）| ±59 in（GPS enabled）| ±4 in（RTK enabled）
RTK Positioning Accuracy: When RTK enabled and fixed: 0.4 in + 1 ppm (Horizontal) | 0.6 in + 1 ppm (Vertical)
Max Angular Velocity: Pitch: 300°/s, Yaw: 100°/s
Max Pitch Angle: 30° (P-mode, Forward Vision System enabled: 25°)
Max Ascent Speed: S Mode: 13.4 mph | P Mode: 11.2 mph
Max Descent Speed (Vertical): S Mode: 11.2 mph | P Mode: 6.7 mph
Max Descent Speed (Tilt): S Mode: 15.7 mph
Max Speed: S Mode: 51 mph | P Mode: 38 mph
Service Cieling Above Sea Level: 16,404 ft (with 2110 propellers, takeoff weight ≤ 15.4 lb) | 22,966 ft (with 2195 propellers, takeoff weight ≤ 15.4 lb)
Max Wind Resistance: 33.5 mph
Max Flight Time: 55 min
Supported DJI Gimbals: Zenmuse XT2 / XT S / Z30 / H20 / H20T
Supported Gimbal Configurations: Single Downward Gimbal, Dual Downward Gimbals, Single Upward Gimbal, Upward and Downward Gimbals, Triple Gimbals
Ingress Protection Rating: IP45
GNSS: GPS + GLONASS + BeiDou + Galileo
Operating temperature: -4°F to 122° F

Remote Controller

Operating Frequency: 2.4000-2.4835 GHz | 5.725-5.850 GHz
Max Transmitting Distance (unobstructed, free of interference): 9.3 mi
EIRP: 2.4000-2.4835 GHz： 29.5 dBm (FCC) | 5.725-5.850 GHz： 28.5 dBm (FCC)
External Battery: WB37 Intelligent Battery - Capacity：4920 mAh - Voltage：7.6V - Type：LiPo - Energy：37.39Wh - Charging time (using BS60 Intelligent Battery Station): 70 minutes (15°C to 45°C)；130 minutes (0°C to 15°C)
Built-In Battery: Type: 18650 li-ion battery (5000 mAh @ 7.2 V) - Charging: USB charger with specification of 12V / 2A - Rated power: 17 W - Charging time：2 hours15 minutes
Battery Life: Built-in battery：Approx. 2.5h | Built-in battery+External battery：Approx. 4.5h
USB Power Supply: 5 V / 1.5 A
Operating Temperature: -4 °F to 104 °F

Vision System

Obstacle Sensing Range: Forward/ backward/ Left/ Right：2.3 - 131 ft | Upward/ downward：2 - 98 ft
FOV: Forward/ backward/ downward：65°（H），50°（V）| Left/ right/ upward：75°（H），60°（V)
Operating Environment: Surfaces with clear patterns and adequate lighting (> 15 lux)

Infrared Sensing System

Obstacle Sensing Range: 0.33 - 26 ft
FOV: 30° (±15°)
Operating Environment:Large, diffuse and reflective obstacles (reflectivity >10%)

Top & Bottom Auxiliary Light

Effective Lighting Distance: 16.4 ft

FPV Camera

Resolution: 960p
FOV: 145°
Frame Rate: 30fps

Intelligent Flight Battery

Name: TB60
Capacity: 5935 mAh
Voltage: 52.8 V
Battery Type: LiPo 12S
Energy: 274 Wh
Net Weight: Approx. 3 lb
Operating Temperature: -4°F to 122°F
Ideal Storage Temperature: 71.6°F to 86°F
Charging Temperature: -4° to 104° F(When the temperature is lower than 5°C, the self-heating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery)
Charging Time: Using BS60 Intelligent Battery Station: 220V input：60 minutes (fully charge two TB60 batteries), 30 minutes (charge two TB60 batteries from 20% to 90%) | 110V input：70 minutes (fully charge two TB60 batteries), 40 minutes (charge two TB60 batteries from 20% to 90%)

BS60 Intelligent Battery Station

Dimensions: 19.7 x 15.9 x 9.9 inch
Net Weight: 18.5 lb
Maximum Capacity: TB60 Intelligent Flight Battery × 8 | WB37 Intelligent Battery × 4
Input: 100-120 VAC, 50-60 Hz / 220-240 VAC, 50-60 Hz
Max Input Power: 1070W
Output Power: 100-120V：750W | 220-240V：992W
Operating Temperature: -4°F to 104°F

Zenmuse H20

General

Dimesions: 5.9 x 4.5 x 5.9 in
Weight: 1.5lb
Protection Rating:IP44
Laser Safety:Class 1M (IEC 60825-1:2014)
Supported Aircraft: Matrice 300 RTK

Gimbal

Angular Vibration Range: ±0.01°
Mount: Detachable

Zoom Camera & Lens

Sensor: 1/1.7" CMOS, Effective Pixels: 20M
Focal Length: 6.83-119.94mm (equivalent: 31.7-556.2mm)
Aperture: f/2.8-f/11 (Normal), f1.6-f/11 (Night)
Focus: 1 m to ∞ (wide), 8 m to ∞ (telephoto)

Wide Camera & Lens

Sensor: 1/2.3“ CMOS, Effective Pixels: 12M
Focal Length: 4.5mm (equivalent: 24mm)
Aperture: f/2.8
Focus: 1 m to ∞

Storage

Supported SD Cards: Supports a microSD card with capacity of up to 128 GB. A UHS-I Speed Grade 3 rating microSD card is required.
Supported File System: FAT32 (≤32 GB), exFAT (>32 GB)

Laser Range Finder

Wavelength: 905nm
Measuring Range: 3-1200 m (20% reflectivity, full spot)
Measuring Accuracy: ± (0.2 m + D×0.15%), D is the distance to a vertical surface
