DSLRPros Matrice 4T Energy & Infrastructure Thermal Inspection Package

DSLRPros Matrice 4T Energy & Infrastructure Thermal Inspection Package

$11,316.00
$11,316.00
Sale Sold out
Shipping calculated at checkout.

B-NB-M4T-EITI

  • Enterprise inspection drone designed for energy and infrastructure operations
  • Multi sensor inspection system with wide, zoom, thermal, laser range finder, and NIR sensors
  • High resolution thermal imaging for detecting overheating and equipment faults
  • Up to 112× hybrid zoom for inspecting distant towers and structures
  • Laser range finder for measuring distances and marking inspection points
  • AI detection tools for improved situational awareness
  • DJI D RTK 3 station included for centimeter level positioning accuracy
  • Three extra flight batteries for extended inspection missions
  • 240W fast charger included for rapid field charging

Request Info / Quote ☎︎ 1 (213) 262-9436
View full details
  • Description
  • Specifications
  • In the Box
  • FAQ

Powerful Multi-Sensor Platform for Critical Infrastructure Inspection

The DSLRPros DJI Matrice 4T Energy & Infrastructure Thermal Inspection Package is a complete enterprise drone solution. It supports professionals who inspect critical energy assets and infrastructure.

Built around the powerful DJI Matrice 4T, this package helps inspection teams work faster and safer. It offers advanced thermal imaging, multi-sensor zoom, and precise positioning tools. These features help teams find faults faster and streamline maintenance operations.

Whether inspecting transmission lines, substations, solar farms, pipelines, bridges, or industrial facilities, the Matrice 4T enables operators to capture detailed visual and thermal data from a safe distance.

The system’s integrated sensors, AI-powered tools, and long-range communication capabilities make it ideal for proactive inspection programs and rapid response to emerging issues.

This inspection-ready bundle enhances operational efficiency with essential accessories including the DJI D-RTK 3 Multifunctional Station for centimeter-level positioning. Three additional Matrice 4 Series batteries are also included for extended missions and a DJI 240W Power Adapter for fast charging in the field.

Key Features at a Glance

  • Multi-sensor inspection platform:– Six integrated sensors including wide, tele, zoom, thermal, laser range finder, and NIR illumination.
  • High-resolution thermal imaging: Detect heat anomalies in power equipment, solar panels, and industrial systems.
  • 112× hybrid zoom: Inspect distant assets like transmission towers and bridge components safely from afar.
  • Laser range finder (LRF): Measure distances, mark coordinates, and calculate inspection areas with precision.
  • AI-powered detection: Automatically identify and track people, vehicles, and vessels during inspection missions.
  • Centimeter-level positioning: DJI D-RTK 3 Station enhances accuracy for mapping and repeatable inspection flights.
  • Extended flight operations: Includes three additional batteries for longer missions and reduced downtime.
  • Enterprise communication system: Long-range OcuSync transmission with optional 4G connectivity.

Purpose-Built for Energy & Infrastructure Inspections

Energy providers and infrastructure operators require precise, reliable data to maintain critical assets and prevent costly failures. The DJI Matrice 4T can capture both visual and thermal data simultaneously, enabling inspectors to quickly identify overheating components, structural issues, and equipment defects.

DJI Matrice 4T in flight at night

Using its powerful zoom cameras and thermal sensor, the Matrice 4T allows inspectors to evaluate powerlines, substations, pipelines, bridges, and industrial facilities without putting personnel in hazardous positions. The drone’s compact yet rugged design enables deployment in remote locations, tight urban environments, and complex infrastructure sites.

High-Precision Thermal Diagnostics

The Matrice 4T’s advanced thermal imaging sensor allows inspection teams to identify abnormal heat signatures in electrical infrastructure and mechanical systems. Thermal imaging is essential for detecting:

  • Overheating transformers and substations
  • Faulty insulators and connectors
  • Defective solar panels or string failures
  • Pipeline leaks and temperature irregularities
  • Mechanical friction or overheating in industrial equipment

By identifying these issues early, maintenance teams can prevent outages, equipment failures, and costly downtime.

Long-Range Visual Inspection with 112× Hybrid Zoom

Energy infrastructure often spans large and difficult-to-access areas. With up to 112× hybrid zoom, the Matrice 4T allows inspectors to examine distant structures such as transmission towers, wind turbines, bridges, and rooftop equipment while maintaining a safe stand-off distance.

The combination of wide, medium telephoto, and high-powered zoom cameras allows operators to quickly transition between situational overview and detailed inspection without repositioning the aircraft.

Laser Range Finder for Precise Measurements

The integrated Laser Range Finder (LRF) enhances inspection accuracy by allowing operators to measure distances, determine coordinates, and calculate areas directly from the controller interface.

This feature is particularly useful for documenting infrastructure locations, mapping inspection zones, and generating precise reports for maintenance planning and asset management.

Centimeter-Level Positioning with DJI D-RTK 3

The included DJI D-RTK 3 Multifunctional Station provides high-precision GNSS positioning that significantly improves mapping accuracy and repeatability for inspection flights.

With RTK support, operators can fly identical inspection routes over time. This allowis maintenance teams to compare historical data, track asset degradation, and detect subtle changes in infrastructure condition.

Reliable Operation in Complex Inspection Environments

Energy and infrastructure inspections frequently occur near steel structures, dense industrial equipment, or environments where GNSS signals are weak. The Matrice 4T incorporates advanced positioning systems and vision sensors that allow stable flight even in challenging conditions.

The aircraft features long-range transmission and optional cellular connectivity. Operators can maintain control and video feeds during inspections across large industrial sites or remote infrastructure corridors.

Extended Mission Capability

This DSLRPros package includes three additional DJI Matrice 4 Series intelligent flight batteries, enabling teams to conduct longer inspection operations with minimal interruption.

The included DJI 240W Power Adapter and charging hub allow rapid battery charging, helping inspection crews stay productive during demanding field operations.

Ideal Applications

Powerline and Transmission Inspection

  • Inspect towers, insulators, and connectors
  • Detect overheating components using thermal imaging
  • Assess vegetation encroachment along transmission corridors

Solar Farm Inspection

  • Detect defective solar panels and hotspots
  • Identify string failures and inverter issues
  • Survey large solar installations quickly

Pipeline and Industrial Infrastructure Monitoring

  • Monitor pipelines for leaks or thermal irregularities
  • Inspect industrial facilities and refineries
  • Evaluate structural integrity of large installations

Bridge and Structural Inspection

  • Inspect structural components safely from the air
  • Identify cracks, corrosion, or heat anomalies
  • Capture detailed visual documentation for engineering analysis

A Complete Inspection Solution from DSLRPros

The DSLRPros DJI Matrice 4T Energy & Infrastructure Thermal Inspection Package delivers everything inspection professionals need to conduct efficient and reliable aerial inspections.

By combining DJI’s latest multi-sensor drone technology with precision RTK positioning and extended power capacity, this package helps teams reduce risk, improve inspection coverage, and capture critical data with confidence.

DSLRPros provides industry-leading support, training, and expertise for enterprise drone programs. Our specialists help organizations deploy advanced UAV systems that enhance safety, efficiency, and operational insight across energy and infrastructure sectors.

Aircraft

  • Takeoff Weight (with propellers): 1219 g* - *The standard weight of the aircraft (including the battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors.
  • Takeoff Weight (with Low-Noise propellers): 1229 g* - *The standard weight of the aircraft (including the battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors.
  • Max Takeoff Weight: Standard Propellers: 1420 g, Low-Noise Propellers: 1430 g
  • Dimensions: Folded: 260.6×113.7×138.4 mm (L×W×H), Unfolded: 307.0×387.5×149.5 mm (L×W×H), Maximum dimensions excluding propellers.
  • Max Payload: 200 g
  • Propeller Size: 10.8 in
  • Diagonal Wheelbase: 438.8 mm
  • Max Ascent Speed: 10 m/s
  • Maximum Ascent Speed With Accessories: 6 m/s
  • Max Descent Speed: 8 m/s
  • Max Descent Speed With Accessories: 6 m/s
  • Max Horizontal Speed (at sea level, no wind): 21 m/s, 21 m/s flying forward, 18 m/s flying backward, 19 m/s flying sideways. No faster than 19 m/s with Sport mode in EU regions.
  • Max Altitude: 6000 m
  • Max Operating Altitude with Payload: 4000 m
  • Max Flight Time (without wind): 49 min (standard propellers), 46 min (low-noise propellers). Measured with the aircraft flying at approximately 8 m/s without payloads in a windless environment until the battery level reached 0%. Data is for reference only. Actual usage time may vary depending on the flight mode, accessories, and environment.
  • Max Hover Time (without wind): 42 min (standard propellers), 39 min (low-noise propellers). Measured with the aircraft flying at approximately 8 m/s without payloads in a windless environment until the battery level reached 0%. Data is for reference only. Actual usage time may vary depending on the flight mode, accessories, and environment.
  • Max Flight Distance (no wind): 35 km (standard propellers), 32 km (low-noise propellers). Measured by the aircraft hovering in a windless environment at sea level, from 100% battery level until 0%.
  • Max Wind Speed Resistance: 12 m/s** Max wind speed resistance during takeoff and landing.
  • Max Pitch Angle: 35°
  • Operating Temperature: -10℃ to 40℃ (14°F to 104°F)
  • GNSS: GPS + Galileo + BeiDou + GLONASS** GLONASS is supported only when the RTK module is enabled.
  • Hovering Accuracy Range (windless or breezy): ±0.1 m (with Vision System); ±0.5 m (with GNSS); ±0.1 m (with RTK)
  • RTK GNSS Accuracy: RTK Fix: 1 cm + 1 ppm (horizontal), 1.5 cm + 1 ppm (vertical)
  • Internal Storage: N/A
  • Ports: E-Port interface × 1: Supports official accessories and third-party PSDK devices (hot-swapping is not supported). E-Port Lite interface × 1: supports USB connection to DJI tuning software and some third-party PSDK devices. Accessories or expansion modules must be installed before powering on.
  • Propeller Model: 1157F (standard propellers), 1154F (low noise propeller)
  • Beacon: Built into the aircraft

Camera

  • Image Sensor: DJI Matrice 4T Wide: 1/1.3-inch CMOS, Effective Pixels: 48 MP, Medium Tele Camera: 1/1.3-inch CMOS, Effective Pixels: 48 MP, Telephoto: 1/1.5-inch CMOS, Effective Pixels: 48 MP, DJI Matrice 4E Wide: 4/3-inch CMOS, Effective Pixels: 20 MP, Medium Tele Camera: 1/1.3-inch CMOS, Effective Pixels: 48 MP, Telephoto: 1/1.5-inch CMOS, Effective Pixels: 48 MP
  • Lens: DJI Matrice 4T FOV: 82°, Equivalent Focal Length: 24 mm, Aperture: f/1.7, Focus: 1 m to ∞, DJI Matrice 4E FOV: 84°, Equivalent Focal Length: 24 mm, Aperture: f/2.8-f/11, Focus: 1 m to ∞, Medium Tele Camera FOV: 35°, Equivalent Focal Length: 70 mm, Aperture: f/2.8, Focus: 3 m to ∞, Tele camera FOV: 15°, Equivalent Focal Length: 168 mm, Aperture: f/2.8, Focus: 3 m to ∞
  • ISO Range: Normal Mode: ISO 100 to ISO 25600, Night Scene Mode: Matrice 4T: Wide Camera: ISO 100 to ISO 409600, Medium Tele Camera: ISO 100 to ISO 409600, Tele Camera: ISO 100 to ISO 819200, Matrice 4E: Wide Camera: ISO 100 to ISO 204800, Medium Tele Camera: ISO 100 to ISO 409600, Tele Camera: ISO 100 to ISO 409600
  • Shutter Speed: DJI Matrice 4T 2-1/8000 s, DJI Matrice 4E Wide: Electronic Shutter: 2-1/8000 s, Mechanical Shutter: 2-1/2000 s, Medium Telephoto: 2-1/8000 s, Telephoto: 2-1/8000 s
  • Max Photo Size: DJI Matrice 4T Wide: 8064 × 6048, Medium Telephoto: 8064 × 6048, Telephoto: 8192 × 6144, DJI Matrice 4E Wide: 5280 × 3956, Medium Telephoto: 8064 × 6048, Telephoto: 8192 × 6144
  • Minimum Photo Interval: DJI Matrice 4T: 0.7 s, DJI Matrice 4E: 0.5 s
  • Still Photography Modes: DJI Matrice 4T: Wide: Single: 12 MP/48 MP, Interval: 12 MP/48 MP, JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s, Smart Shooting: 12MP, Panorama: 12 MP (raw image), 100 MP (stitched image), Medium Tele Camera: Single: 12 MP and 48 MP, Interval: 12 MP/48 MP, JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s, Smart Shooting: 12MP, Telephoto: Single: 12 MP and 48 MP, Interval: 12 MP/48 MP, JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s, Smart Shooting: 12MP, DJI Matrice 4E: Single: 20 MP, Interval: 20 MP, JPEG: 0.5/0.7/1/2/3/5/7/10/15/20/30/60 s, JPEG + RAW: 2/3/5/7/10/15/20/30/60 s, Smart Shooting: 20 MP, Panorama: 20 MP (raw image), 100 MP (stitched image), Medium Tele Camera: Single: 12 MP and 48 MP, Interval: 12 MP/48 MP, JPEG: 0.5/0.7/1/2/3/5/7/10/15/20/30/60 s, Smart Shooting: 12 MP, Telephoto: Single: 12 MP and 48 MP, Interval: 12 MP/48 MP, JPEG: 0.5/0.7/1/2/3/5/7/10/15/20/30/60 s, Smart Shooting: 12 MP
  • Video Codec and Resolution: Video Coding Format: H.264/H.265, Coding Strategy: CBR, VBR, Resolution: 4K: 3840 × 2160@30fps, FHD: 1920 × 1080@30fps
  • Max Video Bitrate: H.264: 60Mbps, H.265: 40Mbps
  • Supported File System: exFAT
  • Photo Format: DJI Matrice 4T: JPEG, DJI Matrice 4E: Wide: JPEG/DNG (RAW), Medium Tele Camera: JPEG, Telephoto: JPEG
  • Video Format: MP4 (MPEG-4 AVC/H.264)
  • Digital Zoom: Telephoto: 16x (112x hybrid zoom)

NIR Auxiliary Light

  • Infrared Illumination: DJI Matrice 4T: FOV: 5.7°±0.3°

Laser Module

  • Laser Rangefinding: Measurement Range: 1800 m (1 Hz) @20% reflectivity target* Oblique Incidence Range (1:5 Oblique Distance): 600 m (1 Hz) Blind Zone: 1 m Distance Measurement Accuracy: 1-3 m: System Error <0.3 m, Random Error <0.1 meters @1σ Other Distances: ±(0.2+0.0015D) (D represents the measurement distance in meters) * Performance degradation may occur in rainy or foggy conditions

Infrared Thermal Camera

  • Thermal Imager: DJI Matrice 4T: uncooled vanadium oxide (VOx) DO NOT expose the infrared camera lenses to strong sources of energy such as the sun, lava, or a laser beam. Otherwise, the camera sensor may be burned leading to permanent damage.
  • Resolution: DJI Matrice 4T: 640 × 512
  • Pixel Pitch: DJI Matrice 4T: 12 μm
  • Frame Rate: DJI Matrice 4T: 30 Hz
  • Lens: DJI Matrice 4T DFOV: 45°±0.3°, DJI Matrice 4T equivalent focal length: 53 mm, DJI Matrice 4T Aperture: f/1.0, DJI Matrice 4T Focus: 5 m to ∞
  • Sensitivity: DJI Matrice 4T: ≤50mk@F1.0
  • Temperature Measurement Method: DJI Matrice 4T: Spot Meter, Area Measurement
  • Temperature Measurement Range: DJI Matrice 4T: High Gain Mode: -20℃ to 150℃ (-4°F to 302°F), Low Gain Mode: 0℃ to 550℃ (32°F to 1022°F)
  • Palette: DJI Matrice 4T: White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2
  • Photo Format: DJI Matrice 4T: JPEG (8bit), R-JPEG (16bit)
  • Video Resolution: DJI Matrice 4T: 1280 × 1024@30fps (Super Resolution enabled, Night Mode not activated), Other conditions: 640 × 512@30fps
  • Video Bitrate: DJI Matrice 4T: 6.5Mbps (H.264 640 × 512@30fps), 5Mbps (H.265 640 × 512@30fps), 12Mbps (H.264 1280 × 1024@30fps), 8Mbps (H.265 1280 × 1024@30fps)
  • Video Format: DJI Matrice 4T: MP4
  • Still Photography Modes: DJI Matrice 4T: Single: 1280 × 1024/640 × 512, Interval: 1280 × 1024/640 × 512, JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s
  • Photo Resolution: DJI Matrice 4T: Infrared: 1280 × 1024 (Super Resolution on), 640 × 512 (Super Resolution off)
  • Digital Zoom: DJI Matrice 4T: 28x
  • Infrared Wavelength: DJI Matrice 4T: 8um to 14um
  • Infrared Temperature Measurement Accuracy: DJI Matrice 4T: High Gain: ±2℃ or ±2%, whichever is greater, DJI Matrice 4T: Low Gain: ±5℃ or ±3%, whichever is greater

Gimbal

  • Stabilization System: DJI Matrice 4T: 3-axis (tilt, roll, pan), DJI Matrice 4E: 3-axis (tilt, roll, pan)
  • Mechanical Range: DJI Matrice 4T Gimbal Mechanical Limits: Tilt: -140° to 113°, Roll: -52° to 52°, Pan: -65° to 65°, Soft Limits: Tilt: -90° to 35°, Roll: -47° to 47°, Pan: -60° to 60°, DJI Matrice 4E Gimbal Mechanical Limits: Tilt: -140° to 50°, Roll: -52° to 52°, Pan: -65° to 65°, Soft Limits: Tilt: -90° to 35°, Roll: -47° to 47°, Pan: -60° to 60°
  • Controllable Rotation Range: DJI Matrice 4T: Pan: ±-90° to 35°, Pan: Not controllable, DJI Matrice 4E: Tilt: -90° to 35°, Pan: Not controllable
  • Max Control Speed (tilt): 100°/s
  • Angular Vibration Range: ±0.007°
  • Yaw Axis: Manual operation is uncontrollable. The MSDK interface program is controllable.
  • Ingress Protection Rating: No Standard Protection Level
  • Operating Temperature: Standard: -10°C to 40°C (14°F to 104°F)

Sensing

  • Sensing Type: Omnidirectional binocular vision system, supplemented with a 3D infrared sensor at the bottom of the aircraft.
  • Forward: Binocular Measurement Range: 0.4-22.5 m, Measurement Range: 0.4-200 m, Obstacle Avoidance Speed: Flight Speed ≤21 m/s, FOV: 90° (horizontal), 135° (vertical)
  • Backward: Measurement Range: 0.4-22.5 m, Measurement Range: 0.4-200 m, Obstacle Avoidance Speed: Flight Speed ≤21 m/s, Field of View (FOV): 90° (horizontal), 135° (vertical)
  • Lateral: Measurement Range: 0.5-32 m, Measurement Range: 0.5-200 m, Obstacle Avoidance Speed: Flight Speed ≤21 m/s, FOV: 90° (horizontal), 90° (vertical)
  • Downward: Measurement Range: 0.3-18.8 m, Obstacle Avoidance Speed: Flight Speed ≤10 m/s, The FOV to the front and rear is 160° and 160° to the right and left.
  • Operating Environment: Forward, Backward, Left, Right, and Upward: Delicate texture on the surface, adequate light. Downward: The ground has rich textures and sufficient lighting conditions*, with a diffuse reflection surface and a reflectivity greater than 20% (such as walls, trees, people, etc.). * Sufficient lighting conditions refer to an illuminance not lower than that of a nighttime city light scene.

Video Transmission

  • Video Transmission System: O4 Enterprise
  • Live View Quality: Remote Controller: 1080p/30fps
  • Operating Frequency: 2.400-2.4835 GHz, 5.725-5.850 GHz, 5.150-5.250 GHz (CE), Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.
  • Transmitter Power (EIRP): 2.4 GHz: ≤33 dBm (FCC), ≤20 dBm (CE/SRRC/MIC), 5.8 GHz: <33 dBm (FCC), <30 dB (SRRC), <14 dBm (CE), 5.15-5.25: <23 dBm (FCC/CE)
  • Max Transmission Distance (unobstructed, free of interference): 25 km (FCC), 12 km (CE), 12 km (SRRC), 12 km (MIC). Measured in an unobstructed environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. During your flight, please pay attention to RTH reminder on the DJI Pilot 2 app.
  • Max Transmission Distance (with interference): Strong Interference - City Centers (approx. 1.5-5 km), Medium Interference - Suburban Areas (approx. 5-15 km), Micro interference: Suburbs/Seasides (approx. 15-25 km). * Data is tested under FCC standards in unobstructed environments of typical interference. Only to serve as a reference and provides no guarantee as to the actual flight distance.
  • Max Download Speed: 20 MB/s. The above data was measured under conditions where the aircraft and remote controller were in close proximity without interference.
  • Latency (depending on environmental conditions and mobile device): 130 ms. Under near-field interference-free conditions, the Latency performance when shooting with a 1x lens.
  • Antenna: 8 antennas, 2T4R
  • Others: Cellular Dongle Compartment

Memory Card

  • Supported SD Cards: U3/Class10/V30 or above is required, or use a memory card from the recommended list.
  • Recommended microSD Cards: Lexar 1066x 64GB U3 A2 V30 microSDXC, Lexar 1066x 128GB U3 A2 V30 microSDXC, Lexar 1066x 256GB U3 A2 V30 microSDXC, Lexar 1066x 512GB U3 A2 V30 microSDXC, Kingston Canvas GO! Plus 64GB U3 A2 V30 microSDXC, Kingston Canvas GO! Plus 128GB U3 A2 V30 microSDXC, Kingston Canvas GO! Plus 256GB U3 A2 V30 microSDXC, Kingston Canvas GO! Plus 512GB U3 A2 V30 microSDXC

Intelligent Flight Battery

  • Capacity: 6741 mAh
  • Standard Voltage: 14.76 V
  • Max Charging Voltage: 17.0 V
  • Cell Type: Li-ion 4S
  • Energy: 99.5 Wh
  • Weight: 401 g
  • Recharging Temperature: 5°C to 40°C (41°F to 104°F)
  • Discharge Rate: 4C
  • Max Charging Power: 1.8C
  • Supports low-temperature charging: Not supported
  • Cycle Count: 200

Power Adapter (100W)

  • Input: 100-240 V (AC), 50-60 Hz, 2.5 A
  • Output: Max. 100 W (total). When both ports are used, the max output power of one port is 82 W, and the charger will dynamically allocate the output power of the two ports according to the power load.
  • Rated Power: 100 W

Charging Hub

  • Input: USB-C: 5-20 V, max 5 A
  • Output: Battery Interface: 11.2 V to 17 V
  • Rated Power: 100 W
  • Recharging Type: 4 batteries charging in sequence. Support Standard Mode (100% SOC) and Standby Mode (90% SOC)
  • Compatible Battery: DJI Matrice 4E/T Series Intelligent Flight Battery
  • Charging Temperature: 5° to 40°C (41°F to 104°F)

DJI RC Plus 2 Enterprise

  • Video Transmission System: O4 Enterprise
  • Max Transmission Distance (unobstructed, free of interference): 25 km (FCC), 12 km (CE), 12 km (SRRC), 12 km (MIC). Measured in an unobstructed environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. During your flight, please pay attention to RTH reminder on the DJI Pilot 2 app.
  • Operating Band of Image Transmission: 2.4000-2.4835 GHz, 5.725 - 5.850 GHz, 5.1GHz (receive only). Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.
  • Antenna: 2T4R, built-in multi-beam high-gain antenna
  • Video Transmission Transmitter Power (EIRP): 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC), 5.1 GHz: <23 dBm (CE), 5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <30 dBm (SRRC)
  • 4G Transmission: DJI Cellular Dongle 2
  • Wi-Fi Protocol: Wi-Fi Direct, Wireless Display, IEEE 802.11a/b/g/n/ac/ax, Support 2 × 2 MIMO Wi-Fi, Dual Band Simultaneous (DBS) with dual MAC, up to 1774.5 Mbps data rate (2 × 2 + 2 × 2 11ax DBS)
  • Wi-Fi Operating Band: 2.4000-2.4835 GHz, 5.150-5.250 GHz. 5.8 and 5.2GHz frequencies are prohibited in some countries. In some countries, the 5.2GHz frequency is only allowed for use in indoor.
  • Wi-Fi Transmitter Power (EIRP): 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC), 5.1 GHz: <23 dBm (FCC), 5.8 GHz <23 dBm (FCC/SRRC), <14 dBm (CE)
  • Bluetooth Protocol: Bluetooth 5.2
  • Bluetooth Operating Frequency: 2.400-2.4835 GHz
  • Bluetooth Transmitter Power (EIRP): <10 dBm
  • Screen Resolution: 1920 × 1200
  • Screen Size: 7.02 inches
  • Screen Frame Rate: 60 fps
  • Brightness: 1400 nits
  • Touchscreen Control: 10 Points Multi-touch
  • Built-in Battery: 2S2P High Energy Density 18650 Lithium-ion Battery (6500 mAh @ 7.2 V) 46.8 Wh
  • External Battery: Optional, WB37 (4920 mAh @ 7.6 V) 37 Wh
  • Recharging Type: Supports PD fast charging, with a maximum specification of 20 V/3.25 A USB Type-C charger.
  • Storage Capacity: ROM 128 G + expandable storage via microSD card
  • Charging Time: 2 hrs for internal battery or internal and external battery. When remote controller is powered off and using a standard DJI charger.
  • Internal Battery Runtime: 3.8 hrs
  • External Battery Runtime: 3.2 hrs
  • Output Port: HDMI 1.4
  • Indicators: Status light & power light & permission light, three-color light, brightness can be adjusted according to ambient brightness.
  • Speaker: Supports buzzer
  • Audio: Array MIC
  • Operating Temperature: -20° to 50° C (-4°F to 122°F)
  • Storage Temperature: Within one month: -30° to 45° C (-22°F to 113°F), One to three months: -30° to 35° C (-22°F to 95°F), Three months to one year: -30° to 30° C (-22°F to 86°F)
  • Recharging Temperature: 5° to 40° C (41°F to 104°F)
  • Supported Aircraft Models: Support for Matrice 4T/4E

AL1 Spotlight

  • Weight: 99 g (including bracket), Approx. 91 g (excluding bracket)
  • Dimensions: 95×164×30 mm (L×W×H, including bracket), 79×164×28 mm (L×W×H, without bracket)
  • Max. Power: 32 W
  • Illuminance: 4.3±0.2 lux @ 100 meters, 17±0.2 lux @ 50 meters. The data was measured in a laboratory environment with the spotlight installed separately on the aircraft at an ambient temperature of 25°C.
  • Effective Illumination Angle: 23° (10% relative illumination)
  • Effective Illumination Area: 1,300 square meters @ 100 meters (10% relative illumination, Normal Mode), 2,200 square meters @ 100 meters (10% central illuminance, Wide FOV Mode)
  • Operating Mode: Supports always-on and strobe modes.
  • Gimbal Structural Design Range: Tilt: -140° to 50°
  • Controllable Range: Tilt: -90° to 35°
  • Max Control Speed (tilt): 120°/s
  • Gimbal Alignment Accuracy: ±0.1°
  • Operating Temperature: -20°C to 50°C (-4°F to 122°F)
  • Mounting: Quick-release hand-tightened screws

AS1 Speaker

  • Weight: 92.5 g (including bracket), Approx. 90 g (excluding bracket)
  • Dimensions: 73×70×52 mm (L×W×H, including bracket), 73×70×47 mm (L×W×H, without bracket)
  • Max. Power: 15 W
  • Max. Volume: At 1 meter, it can reach 114 decibels (114dB@1m). Data measured in a laboratory environment at 25℃. Actual conditions may vary slightly due to software version, audio source, specific environment, and other factors. The final effect is subject to actual use.
  • Effective Broadcast Distance: 300 m. Data measured in a laboratory environment at 25℃. Actual conditions may vary slightly due to software version, audio source, specific environment, and other factors. The final effect is subject to actual use.
  • Broadcast Mode: Real-time broadcasting (supports echo suppression*), recorded broadcasting, media import (supports simultaneous transmission and playback), text-to-speech*** Need to upgrade to the latest firmware. ** Currently only supports Chinese and English.
  • Operating Temperature: -20°C to 50°C (-4°F to 122°F)
  • Mounting: Quick-release hand-tightened screws
  • 1x DJI Matrice 4T
  • 1x DJI Matrice 4 Series Battery
  • 1x DJI RC Plus 2 Enterprise
  • 1x DJI 100W USB-C Power Adapter
  • 1x DJI Matrice 4 Series Charging Hub
  • 1x microSD Card
  • 1x DJI Matrice 4T Gimbal Protector
  • 1x DJI Cellular Dongle 2 Pry Bar
  • 3x DJI Matrice 4 Series Propellers
  • 1x 100W Power Adaptor AC Cable
  • 1x USB-C to USB-C Data Cable
  • 1x USB-A to USB-C Data Cable
  • 1x DJI Matrice 4 Series Storage Case
  • 1x DJI Matrice 4 Series Storage Case Shoulder Strap

Also included:

  • 1x DJI D-RTK 3 Multifunctional Station
  • 3x Extra DJI Matrice 4 Series Batteries
  • 1x DJI 240W Power Adapter for Matrice 4/4D Series
  • 2x DJI WB37 Intelligent Batteries (4920mAh)
  • 1x DJI WB37 Battery Charging Hub (USB-C)
  • 1x Drone Landing Pad
What cameras are included on the DJI Matrice 4T?

It includes wide-angle, telephoto, and thermal cameras for layered imaging.

What is the maximum flight time of the DJI Matrice 4T?

The Matrice 4T supports up to 47 minutes of maximum flight time.

How far can the telephoto camera zoom on the Matrice 4T?

The telephoto camera supports up to 16× digital zoom and 112× hybrid zoom, allowing officers to observe incidents or hazards from safe distances without approaching the scene.

What is the main difference between the Matrice 4E and Matrice 4T?

The Matrice 4E and Matrice 4T share the same airframe, many common features and flight performance, but differ primarily in their camera/ sensor payloads.

  • The Matrice 4E is optimized for surveying/mapping: it features a 4/3-inch CMOS 20 MP wide-angle camera (mechanical shutter), plus the 48 MP medium-tele and 48 MP telephoto cameras.
  • The Matrice 4T replaces the wide-angle 4/3″ camera with a 1/1.3″ 48 MP wide camera, and adds a thermal imaging sensor, making it more suited for inspections, public safety or emergency response.
  • Both have similar flight time (~49 minutes) and core specs.

So if your focus is mapping/surveying, the 4E is ideal. If you need thermal imaging/inspections, the 4T is better.

What is the difference between Standard Mode and Ready-to-Fly Mode on the DJI Matrice 4 Series Charging Hub (100W)?

Standard Mode charges each battery to 100% SOC sequentially. Ready-to-Fly Mode charges to 90% SOC and maintains that level for faster deployment.

What charging system works with the DJI Matrice 4 Series Battery?

It is designed for use with the DJI Matrice 4 Series Charging Hub.

What is the energy capacity of the DJI Matrice 4 Series Battery?

The battery provides 99.5 Wh of energy for extended enterprise missions.

How long can the DJI Matrice 4 Series Battery fly?

It supports up to 49 minutes of flight time or 42 minutes of hover time under optimal conditions.

Is the Matrice 4 Series NDAA-compliant for U.S. government procurement?

No.

Does the Matrice 4 Series support RTK or GNSS for surveying accuracy?

Yes, the Matrice 4 Series is designed for enterprise surveying and mapping, and supports high-precision positioning modules (RTK) to enable centimeter-level accuracy.
