DJI 240W Charging Hub for Matrice 4D Series

DJI 240W Charging Hub for Matrice 4D Series

$152.00
$152.00
Sale Sold out
Shipping calculated at checkout.

S-DJI-M4D-CHG

SKU S-DJI-M4D-CHG MPN CP.EN.00000627.01 EAN 6937224106352
  • High capacity sequential charging for three 149.9Wh Matrice 4D flight batteries
  • Intelligent prioritization charging the battery with shortest remaining time first
  • Ready-to-Fly mode maintaining batteries at 90 percent for rapid deployment
  • Mobile power compatibility with DJI Power Series via SDC cable
  • Dedicated USB-C assistant port for internal charging hub firmware updates
  • Multi-color status LED providing real-time feedback on charging and health
  • Wide operating temperature range from 41 to 104 degrees Fahrenheit
  • Required 240W power adapter support for maximum sequential charging efficiency
  • Professional 3-port configuration designed for Matrice 4D series aircraft batteries
Request Info / Quote ☎︎ 1 (213) 262-9436
View full details
  • Description
  • Specifications
  • In the Box
  • FAQ

DJI Matrice 4D Series 240W Charging Hub: Rapid power management

The DJI Matrice 4D Series 240W Charging Hub is a high-performance power management solution engineered for the professional DJI Matrice 4D and 4TD platforms. This advanced hub facilitates the efficient charging of 149.9Wh Intelligent Flight Batteries, ensuring your fleet remains operational during demanding production schedules. By utilizing the required DJI 240W Power Adapter, the hub can sequentially charge multiple batteries using intelligent logic that prioritizes the unit with the shortest remaining charging time. This streamlined process minimizes downtime in the field, allowing flight teams to focus on capturing critical data and cinematic imagery without the delay of manual battery rotation.

DJI Matrice 4D Series 240W Charging Hub core features and advantages

  • Standard mode sequentially charges each individual battery to a full 100 percent capacity.
  • Ready-to-Fly mode charges batteries to 90 percent and maintains that level for rapid use.
  • Intelligent prioritization automatically charges the battery with the shortest remaining time first.
  • Mobile power support enables connection to DJI Power Series stations via SDC cable.
  • Firmware updates are easily managed through the dedicated onboard USB-C assistant port.
  • Status monitoring via integrated LED indicates charging progress and temperature alerts.
  • Safe operation design requires placement on flat stable surfaces for optimal insulation.
  • Wide input voltage range supports 16.8 to 25.5 V at 12.1 A max.

The DJI Matrice 4D Series 240W Charging Hub provides the dependable power infrastructure necessary for sustained professional aerial operations. By offering specialized charging modes and intelligent battery prioritization, this hub solves the problem of logistical delays during high-stakes missions. It is a vital tool for ensuring long-term hardware reliability and maintaining a consistent operational tempo in any professional environment.

DSLRPros leverages decades of UAS industry experience to provide professional-grade power solutions that integrate seamlessly into your enterprise fleet. We offer more than just hardware; we deliver complete UAV lifecycle support to ensure your public safety or industrial operations remain safe and efficient. Optimize your mission readiness by purchasing the DJI Matrice 4D Series 240W Charging Hub from DSLRPros.

  • Input: SDC 16.8 V – 25.5 V, 12.1 A
  • Rated power: 240 W
  • Type of charge: sequential (up to three batteries)
  • Charging modes:Standard: charges each battery to 100%.Ready to fly: charges each battery to 90% and maintains this level
  • Compatible batteries: DJI Matrice 4D Series batteries
  • Charging temperature: 5°C – 40°C (41°F – 104°F)
  • 1x Charging Hub
  • 1x SDC Cable
Which batteries are compatible with this charging hub?

This charging hub is designed exclusively for the Matrice 4D Intelligent Flight Battery used by the DJI Matrice 4D series. It is optimized for the 149.9Wh high-capacity cells required for professional aerial cinema and thermal missions. You should not use this hub with other battery models, as it is engineered with specific voltage and terminal configurations for the Matrice 4D platform.

What is the difference between Standard and Ready-to-Fly modes?

Standard mode sequentially charges each inserted battery to 100% capacity to ensure maximum possible flight time. Ready-to-Fly mode charges each battery to 90% in sequence and then maintains that level to prevent the natural degradation that occurs when batteries sit at 100% for too long. This mode is ideal for pilots who need to be ready for immediate deployment throughout the day.

Can I charge all my batteries at the exact same time?

The hub operates using sequential charging logic, meaning it charges one battery at a time rather than all simultaneously. To save time, the hub automatically detects the current charge level of each battery and begins charging the one with the shortest remaining time first. This ensures you have at least one fully powered battery available as quickly as possible.

What does it mean if the status LED is blinking red?

A solid red LED indicates an unrecoverable abnormality with either the battery or the charging hub itself. If you encounter this error, you should first try removing and reinserting the battery to ensure a clean connection. If the red light persists, unplug the power adapter and then plug it back in; if the problem remains, contact your distributor for technical support.

Is a power adapter included with the charging hub?

This package includes the charging hub and an SDC cable. It does not include the primary wall adapter; the DJI 240W Power Adapter is required separately to power the hub for standard wall-outlet charging. The hub can also be powered by DJI Power Series stations using the included SDC cable for field operations.
